To remove and replace the backlight inverter board
1 Perform previous procedures:
• “To prepare the instrument for disassembly” on
page 46.
• “To remove and replace the cover” on page 50.
• “To remove and replace the front panel assembly” on
page 57.
2 Using a Torx T10 screwdriver, remove the 7 screws
securing the front panel plate to the front panel.
