Agilent Technologies 16901A

60 16901A Logic Analysis System Service Guide
6 Replacing Assemblies
3 Disconnect the backlight cables from the inverter board.
4 Using a Torx T6 screwdriver, remove the 2 screws
securing the board to the front panel.
5 Remove the board.
6 Reverse this procedure to install the backlight inverter
board.
Backlight
inverter
board
backlight cables
T-6
screws
(2)
