24 16900 Series Logic Analysis Systems Installation Guide
2 Installing Logic Analyzer Cards and Probes
To connect probes
Probing is the key to effective and efficient use of logic analyzers. Agilent
Technologies offers a wide variety of probing accessories that support
general- purpose and application- specific measurement needs. We provide
reliable, electrically and mechanically unobtrusive probes that make it easy
to connect your Agilent logic analyzer to your system under test. For more
information on Agilent probes:
• See the quick reference card that came with your logic analysis system
for an overview of probing solutions.
• Go to www.agilent.com/find/logic_analyzer_probes for the most
up- to- date information on probe compatibility with a given logic
analyzer and purchasing information.
• Go to www.agilent.com and search for Probing Solutions for Logic
Analyzers (publication 5968- 4632E) for a catalog of detailed probing
information.
To connect and set up a probe, follow the instructions in the User’s Guide
that came with the probe.
To replace thumb screws on measurement modules
If you ordered measurement modules with your logic analysis system, they
will have the proper thumb screws and you can skip this procedure.
If you are using a measurement module from a 16700 Series logic analysis
system, you may need to replace the thumb screws. The rigid screws on
these modules are not compatible with the new ejector levers.
1 Remove the retaining ring from the back of the panel then remove the
thumb screw.
The 16900 series of Logic Analysis systems with serial number of MY51420101 or higher
require the Agilent Logic Analyzer software version 5.20 or later. These systems have the
Windows 7 operating system installed.
