Agilent Technologies 16901A User Manual

Installing Logic Analyzer Cards and Probes 2
16900 Series Logic Analysis Systems Installation Guide 25
2 Insert the module sleeve into the front of the module panel and screw
the nut onto it.
3 Screw the module screw into the sleeve.
The 16900A/16902A logic analysis system comes with a set of 6
replacement thumb screws (16900- 68713), and the 16903A logic analysis
system comes with a set of 2 replacement thumb screws (16903- 68713).
Thumb
screw
Retaining
ring
Module
sleeve
Hex nut
Module
screw
