Agilent Technologies 16901A

58 16901A Logic Analysis System Service Guide
6 Replacing Assemblies
5 Using a Torx T10 screwdriver, remove 6 screws that
secure the front panel to the chassis.
6 Remove the front panel assembly.
7 Reverse this procedure to install the front panel assembly.
T-10
screws (3)
USB
cables
T-10
screws (3)
Display
cable
Touch screen
cable
Front panel
cable
Keyboard
cable
