Agilent Technologies 16901A

56 16901A Logic Analysis System Service Guide
6 Replacing Assemblies
3 Using a 5 mm hex nut driver, remove the 6 Hex Studs
securing the connectors to the rear panel.
4 Using a Torx T10 screwdriver, remove the 8 screws that
secure the motherboard to the deck.
5 Reverse this procedure to install the motherboard.
5 mm hex
studs (6)
T-10
screws
(8)
