Agilent Technologies 33250A Service Guide

142
Chapter 6 Service
Disassembly
6
5 Remove the screw in the bottom of the instrument cover.
Slide off the cover.
6 Remove the screw securing the top shield. Slide the shield back and then
up to lift off. The A3 power supply assembly is attached to the top shield.
Remove screw
Slide Cover Off
