Chapter 4 Calibration Procedures

0 dB Range Flatness Adjustments

1 Connect the power meter as shown on page 83.

2 Use the power meter to measure the output amplitude for each of the

setups in the table below.

Note Setup 44 establishes the power meter reference for all the remaining

setups in this table. You must always perform setup 44 before any of the

following setups.

* Constants are stored after completing this setup.

Continued on next page...

Nominal Signal

Setup Frequency Amplitude

44* 100 kHz 0.28 Vrms 2 dBm Power Meter Reference for 0 dB Range

45* 200 kHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

46* 500 kHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

47* 1.5 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

48* 5 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

49* 10.1 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

50* 25.1 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

51* 40.1 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

52* 50.1 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

53* 60.1 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

54* 65.1 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

55* 70.1 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

56* 75.1 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter

57* 79.9 MHz 0.28 Vrms 2 dBm Flatness for 0 dB, Elliptical Filter
