Agilent Technologies 33250A - Page 173

173
Chapter 7 Replaceable Parts
33250-66511 – Main PC Assembly (A1)
4
7
U603 1826-2147 5 ANALOG MULTIPLEXER 8 CHNL 16 -P-SOIC 02883 DG408DY
U604 1826-2176 4 IC OP AMP PRCN DUAL 8 PIN PLSTC-SOIC 03285 AD712JR
U605 1813-1449 1 Crystal-Clock Oscillator 09235 F3345-15.000MHZ
U606 1826-6561 1
IC-AD-16BPAR/SER-51G/DEL-EXT-AD7721AR 03285 AD7721AR
U607 1826-2793 2 D/A 16-BIT 16-P-SOIC BICMOS 03285 AD1851R
U608 1820-4346 1
IC MUXR/DATA-SEL CMOS/HC 2-TO-1-LINE TPL 02910 74HC4053D
U609 1826-2176 IC OP AMP PRCN DUAL 8 PIN PLSTC-SOIC 03285 AD712JR
U701 1826-6642 1 D/A 14-BIT 14-SOIC +5V SERIAL INPUT 11302 MAX545BCSD
U702 1826-2176 IC OP AMP PRCN DUAL 8 PIN PLSTC-SOIC 03285 AD712JR
U703 1826-2147 ANALOG MULTIPLEXER 8 CHNL 16 -P-SOIC 02883 DG408DY
U704 1826-1622 3 IC OP AMP LOW-BIAS-H-IMPD QUAD 14 PIN 01698 TL074CD
U705 1826-2176 IC OP AMP PRCN DUAL 8 PIN PLSTC-SOIC 03285 AD712JR
U706 - U708 1826-2147 ANALOG MULTIPLEXER 8 CHNL 16 -P-SOIC 02883 DG408DY
U801 1826-1734 1 IC PWR MGT-V-REG-FXD-POS 4.8/5.2V 3 PINS 01698 UA78M05CKTP
U802 1826-2387 1 IC COMPARATOR HS 14 PIN PLSTC-SOIC 02910 NE529D
U803 1813-1433 1 TCXO 10 MHZ 5V CMOS 14847
TV2045A-LX-1-10.000
U804 1820-5938 IC GATE CMOS/ACT NAND QUAD 2-INP 01698 SN74ACT00D
U901 1827-0030 2 IC FREQ-SYNTH 20 PIN PLSTC-TSSOP 03406 LMX2332LTM
U902 1826-3184 5 IC OP AMP LP 5 PIN PLSTC SOT23-5 03406 LMC7101AIM5
U903 1813-1506 1 PRECISION VCXO 797 to 803MHZ 12685 CLV0795E
U904 1827-0030 IC FREQ-SYNTH 20 PIN PLSTC-TSSOP 03406 LMX2332LTM
U905 1826-3184 IC OP AMP LP 5 PIN PLSTC SOT23-5 03406 LMC7101AIM5
U906 1821-0459 2 IC GATE ECL/10E AND-NAND 2-INP 36633 MC10EL05D
U907 1820-7756 1 IC MISC ECL/10E 36633 MC10E195FN
U1001 1990-2050 40 NS PROP DELAY, SO-8 OPTOCOUPLER 02364 HCPL-0710
U1002 1820-8770 1 IC BFR CMOS/ACT NON-INV QUAD 02237 74ACT125SCX.
U1003 1990-2050 40 NS PROP DELAY, SO-8 OPTOCOUPLER 02364 HCPL-0710
U1004 1826-3813 3 IC-COMP SPT9687, DUAL HIGH-SPEED 13735 SPT9687SIS
U1005 1820-5606 2 IC GATE ECL/10KH AND QUAD 2-INP 36633 MC10H104FNR2
U1006 1826-1622 IC OP AMP LOW-BIAS-H-IMPD QUAD 14 PIN 01698 TL074CD
U1007 1821-0442 3 IC FF ECL/10E D-TYPE POS-EDGE-TRIG 36633 MC10EL31D
U1008 1821-0882 1 IC GATE ECL/10E 36633 MC10EL89D
U1009 1826-2793 D/A 16-BIT 16-P-SOIC BICMOS 03285 AD1851R
U1101 1821-0076 2 IC RGTR ECL/10E 5-BIT 36633 MC10E452FN
U1102 - U1103 1821-0658 2 IC DIVR ECL/10E DIV-X-4 36633 MC10EL33D
U1104 1821-0459 IC GATE ECL/10E AND-NAND 2-INP 36633 MC10EL05D
U1105 1821-3534 1 IC-MC10EL51D, FF, D-TYPE W/DIFF CLOCK 36633 MC10EL51D
U1106 1821-1985 1
IC-MC10E404FN, GATE, QUAD DIFF AND/NAND 36633 MC10E404FN
U1107 1820-7650 2 IC GATE ECL/10E AND-NAND QUINT 2-INP 36633 MC10E104FN
U1108 1821-0442 3 IC FF ECL/10E D-TYPE POS-EDGE-TRIG 36633 MC10EL31D
U1109 1820-6946 2 IC FF ECL/10E D-M/S POS-EDGE-TRIG COM 36633 MC10E131FN
U1110 1821-0442 IC FF ECL/10E D-TYPE POS-EDGE-TRIG 36633 MC10EL31D
U1111 1820-5390 3 IC XLTR ECL/10KH ECL-TO-TTL QUAD 36633 MC10H125FN
U1201 1821-8744 1 IC PLD CPLD UNPRGMD CMOS 1K30 12880 EP1K30FC256-3
U1202 1820-5940 1 IC GATE CMOS/ACT AND QUAD 2-INP 02237 74ACT08SCX
Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
