Agilent Technologies 33250A Service Guide

175
Chapter 7 Replaceable Parts
33250-66511 – Main PC Assembly (A1)
4
7
VR804 1901-1276 DIODE, TRANSORB-ZENER 02664 SMBJ5.0A
VR805 0960-1073
ESD SUPPRESS OR (COL/01556-66501/ODIN) 02805 0805ESDA
VR1001 1901-1276 DIODE, TRANSORB-ZENER 02664 SMBJ5.0A
VR1002 0960-1073
ESD SUPPRESS OR (COL/01556-66501/ODIN) 02805 0805ESDA
VR1501 1901-1276 DIODE, TRANSORB-ZENER 02664 SMBJ5.0A
VR1502 0960-1073
ESD SUPPRESS OR (COL/01556-66501/ODIN) 02805 0805ESDA
VR1503 1901-1346 DIO,TVS,D0214AB,43V,1500WP,SMCJ43CA 22280 SMCJ43CA
VR1901 1901-1276 DIODE, TRANSORB-ZENER 02664 SMBJ5.0A
VR1902 0960-1073
ESD SUPPRESS OR (COL/01556-66501/ODIN) 02805 0805ESDA
VR1903 1901-1346 DIO,TVS,D0214AB,43V,1500WP,SMCJ43CA 22280 SMCJ43CA
VR2001 1901-1346 DIO,TVS,D0214AB,43V,1500WP,SMCJ43CA 22280 SMCJ43CA
XJ1501 3050-1557 WASHER - FLAT 05313 5606-4-31
XJ1901 3050-1557 WASHER - FLAT 05313 5606-4-31
XJ9 33120-00614 SHIELD - RFI 02362 33120-00614
XU105 1200-1592 1
SOCKET-IC-PLCC 44-CONT SQUARE J-LEAD 01380 3-822275-1
XU207 - XU210 1200-1593 4 SOCKET-IC-PLCC 32-CONN RECT J-LEAD 01380 3-822273-1
XU301 1200-1590 1
SOCKET-IC-PLCC 20-CONT SQUARE J-LEAD 01380 3-822269-1
Y101 0410-4009 1 CERO-RES 12MHZ +1-0.8% 02010 PBRC-12.00BR07
Y102 0410-2622 1 CRYSTAL-QUARTZ 3.6864 MHZ 09235 FPX0368-20
Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
