Agilent Technologies 4UHV User Manual

Technical Information
Start-Up
5
Agilent 4UHV Ion Pump Controller User Manual / 87-900-137-01 (A) 69/104
Digital Output
Pin 14 CH2 NC Set-point Relay
Pin 15 CH2 (Common) Relay
Pin 16 CH2 NO Set-point Relay
Channel 3
Input
Pin 23 CH3 on/off
Pin 24 CH3 protect
Pin 25 CH3 step
Pin 22 Digital Gnd
Analog Output
Pin 20 Analog 3
Pin 3 Analog Gnd
Digital Output
Pin 35 CH3 NC Set-point Relay
Pin 36 CH3 (Common) Relay
Pin 37 CH3 NO Set-point Relay
Channel 4
Input
Pin 26 CH4 on/off
Pin 27 CH4 protect
Pin 28 CH4 step
Pin 22 Digital Gnd
Analog Output
Pin 21 Analog 4
Pin 3 Analog Gnd
Digital Output
Pin 32 CH4 NC Set-point Relay
Pin 33 CH4 (Common) Relay
Pin 34 CH4 NO Set-point Relay
