78/104 Agilent 4UHV Ion Pump Controller User Manual / 87-900-137-01 (A)
The controller can reply with the following types of response:
Table 7
Type Length Value Description
Logic - After a read instruction of a logic window.
Numeric 6 bytes - After a read instruction of a numeric window.
Alphanumeric 10 bytes - After a read instruction of a alphanumeric window.
ACK 1 byte (0x6) Execution of the command has been successful.
NACK 1 byte (0x15) Execution of the command has failed.
Unknown Window 1 byte (0x32) The window specified in the command is not a valid window.
Data Type Error 1 byte (0x33) The data type specified in the command (Logic, Numeric or
Alphanumeric) is not in agreement with the Window
specified.
Out of Range The value expressed during a write command is not within
the range value for the specified window.
Win Disabled 1 byte (0x35) The window specified is Read Only or is temporarily disabled.
Table 8 Windows Description
WIN R/W Type Description Range
11 R/W L HV ON/OFF
CH1
0 = OFF(def) ; 1=ON
12 R/W L HV ON/OFF
CH2
0 = OFF(def) ; 1=ON
13 R/W L HV ON/OFF
CH3
0 = OFF(def) ; 1=ON
14 R/W L HV ON/OFF CH4 0 = OFF(def) ; 1=ON
108 R/W N Baud rate (1-4) [1200-2400-4200-9600]
205 R N Status
206 R N Error code
319 R/W Controller Model
323 R/W Controller Serial number
503 R/W N RS485 Serial Address [0-31]; 1=def
504 R/W L Serial Type Select 0= RS232(def) ;
