Agilent 4UHV Ion Pump Controller User Manual / 87-900-137-01 (A) 79/104

WIN R/W Type Description Range

1= RS485

505 R/W N Channel Selection (see below)

600 R/W N Unità di misura

Pressione

0 = Torr ;

1=mBar (def) ;

2=Pa

601 R/W A Operating Mode (see below)

602 R/W A Protect (see below)

603 R/W A Fixed/Step (see below)

610 R/W N Device Number CH1 (see below)

612 R/W N Power max CH1 20 W – 80 W

613 R/W N V target CH1 [3000,7000] V

step 1000;

def=7000

614 R/W N I protect CH1 [1,100] step 1 mA

615 R/W A Set Point CH1 [X.XE-XX]

620 R/W N Device Number CH1 (see below)

622 R/W N Power max CH2 20 W – 80 W

623 R/W N V target CH2 [3000,7000] V

step 1000;

def=7000

624 R/W N I protect CH2 [1,100] step 1 mA

625 R/W A Set Point CH2 [X.XE-XX]

630 R/W N Device Number CH3 (see below)

632 R/W N Power max CH3 20 W – 80 W

633 R/W N V target CH3 [3000,7000] V

step 1000;

def=7000

634 R/W N I protect CH3 [1,100] step 1 mA

635 R/W A Set Point CH3 [X.XE-XX]

640 R/W N Device Number CH4 (see below)

642 R/W N Power max CH4 20 W – 80 W

643 R/W N V target CH4 [3000,7000] V
