1 Parameter Menu of the Controller (Firmware V1.10)
Parameter
Assignment min value max value default
0 1000 (Password) 10 0x7fff 1000
1 Temp. adjustment (0.1°C) -200 200 -23
2 LCD contrast 0 50 20
3 push rod position outside (min pos) -400 -100 -136
4 push rod position ion source (max pos)
300 550 467
5 cooling position 100 500 300
6 max temperature 350 500 400
7 xp*0.1 10 1000 150
8 tn*0.1 1 100 40
9 inj-position -400 -100 -135
10 ion source position 300 500 444
11 temp correction (*0.001) -200 200 -115
12 damp down heating oscillations td*0.1 0 30 10
13 O-ring change position -400 0 -115
14
Option bits: 1=useExStart, 2=ready
position inside the DIP, 4=90°position,
8=continuous operation, 16=smoothing
of temperature, 32=early start,
64= CO
2
cooling
-0x8000 0x7fff 23
15 push rod horizontal position -0x8000 0x7fff 75
16 light barrier change position - - 160
17 tilt angle adjustment - - 12
18
dwell time (in valve after opening to the
ion source; 1min =100, default = 6 s)
0 -001
19
position of light barrier for tube test
(-97 = activated, -1 = deactivated)
-97
Additional remarks to parameter 14:
You can combine the items by adding the numbers, e. g. “23” (1+2+4+16) for DIP without autosampler or
“31” (1+2+4+8+16) for DIP with autosampler, “95” ((1+2+4+8+16+64) for DIP with autosampler and CO
2
cooling
