3 Installing Intuvo 9000 GC Columns

To Replace an Intuvo GC Column

60 5977C GC/MSD Operating Manual

4 Open the GC front door. (See Figure 10.)

5 Open the bus door and remove it by lifting the door vertically off its hinge

pins.

6 Lower the oven door.

Figure 10. 9000 GC front door, bus door, oven door, and Intuvo torque driver

Bus door

Oven door

Intuvo torque driver

Front door
