Agilent Technologies 8890 - Gas Sample Selector Bag Version

Introduction 2
Gas Sample Selector bag version
Agilent Gas Sample Selector for 8860 and 8890 User Manual 17
Gas Sample Selector bag version
Figure 1 Gas Sample Selector bag version, front view.
Table 1 LED state indicator light guide
Light color Indication
Red Error
Green Ready
Yellow Not ready
Power button
State indicator light (LED)
Sample position
indicator lights
