2-2 Chapter 2
Preparing to Make GSM Measurements
GSM Measurements
GSM Measurements
The following GSM measurements are available in GSM mode and
described in this document:
❏
“Making the Monitor Band/Channel Measurement” on page 4-3.
❏
“Making the Out-of-Band Spurious Measurement” on page 4-6.
❏
“Making the Output RF Spectrum (ORFS) Measurement” on page 3-3.
❏
“Making the Phase and Frequency Error Measurement” on page 3-10.
❏
“Making The Power Steps Measurement” on page 3-17.
❏
“Power Time Custom Masks” on page 3-14.
❏
“Making The Transmitter Receive (Rx) Band Spurious Measurement” on
page 4-10
.
❏
“Making the Transmitter Transmit (Tx) Band Spurious Measurement” on
page 4-14
.
❏
“Making the Transmitter Power Measurement” on page 3-19.
These are referred to as one-button measurements. When you press the
key to select the measurement it becomes the active measurement,
using settings and a display unique to that measurement. Data
acquisitions automatically begin provided trigger requirements, if any,
are met.
In addition to the above, the following manual measurements
(measurements which are not activated by a single key-press) are also
described in this document:
❏
“Cable fault location (performed in GSM mode).” on page 5-2.
❏
“Loss/Gain Measurement Set-up” on page 5-13.
❏
“Return loss (VSWR) (performed in SA mode).” on page 5-2.
