2-6 Chapter 2
Preparing to Make GSM Measurements
Preparing to Make Measurements
The primary keys required for performing one button measurements
are shown in
Figure 2-2 on page 2-5
How to Save Measurement Results
To save measurement results, follow the process shown below. For
additional information on file management in the spectrum analyzer,
refer to the ESA Spectrum Analyzers User’s Guide.
1. Press
File, Save, Type, More, Measurement Results.
2. If you want to change the file name, press
Name, and use the Alpha
Editor the enter the new name. For more information on using the
Alpha Editor, refer to the ESA Spectrum Analyzers User’s Guide.
3. Press
Save Now to complete the file saving process.
4. If you have used the default file name and wish to save additional
measurement results, press
Save. The current measurement result
will be saved with the next default file name.
5. If you have not used the default file name and wish to save
additional measurement results, repeat steps 1 through 3.
