Replacing The Chassis Assembly
1 Remove the Power Meter Cover as shown in “Removing the Power Meter
Cover” on page 95.
2 Disassemble the power meter down to allow access to the rear panel
connectors (Refer to “Removing the A4 Comms Assembly” on page 99).
3 For Standard or Option #002 models, disconnect the Power Reference Cable
from the Front Panel Assembly.
4 For Option #003 units, disconnect the Power Reference Cable from the
Chassis Assembly (rear panel).
5 Remove the A3 Front Panel Assembly as shown in “Removing the A3 Front
Panel Assembly” on page 105.
6 For Option #002 or Option #003 models, remove the Rear Panel Power
Sensor Cable Assemblies as shown on “Replacing the Rear Panel Power
Sensor Cable Assemblies (Options 002 and 003)” on page 109.
7 For Option #003 units, remove the Rear Panel Power Reference Connector
as shown on “Replacing the Rear Panel Power Reference Cable Assembly
(Option 003)” on page 111.
8 Remove the Recorder Output(s) Cable Assembly as shown on “Replacing the
Rear Panel Recorder Output(s) Cable Assembly” on page 112.
9 Remove all blanking plugs from the rear panel.
10 Obtain the new Chassis Assembly, and then re- assemble the Power Meter
by following steps 1 to 9 in reverse order.
When replacing the power supply unit in the power meter, ensure that all earth
wiring is reconnected. There are two terminals to check, the first is the force fit
connector to the power supply unit and the second a closed loop terminal
bonded to the chassis with an M3.5 machine screw (use a 9 lb/in T15 screw
driver). All the protective earth wiring can be identified by the insulation color
green with a yellow stripe.
Once re-assembly is complete, the unit must be safety-tested in accordance
with local guidelines and procedures. This safety-test may take the form of an
Earth Continuity Test, Hi-Pot Test, etc.
