Performance Tests 2
E4416A/E4417A Power Meters Service Guide 57
Performance Test Record
Model Agilent E4416A/E4417A Power Meter
Tested by _____________________________
Serial Number _________________________
Date ________________
Ta bl e 2 - 9 Performance Test Record
Test Min Result Channel A Actual
Result
Channel B Actual
Result
Max Result
Zero Test
−76.40 nW ______________ ______________ +76.40 nW
Instrument Accuracy
3.1623 μW 3.0977 μW ______________ ______________ 3.2269 μW
10 μW 9.904 μW ______________ ______________ 10.096 μW
31.6228 μW 31.428 μW ______________ ______________ 31.819 μW
100 μW99.49 μW ______________ ______________ 100.51 μW
316.227 μW314.72 μW ______________ ______________ 317.74 μW
1 mW 0.9954 mW ______________ ______________ 1.0047 mW
3.1623 mW 3.1477 mW ______________ ______________ 3.1769 mW
10 mW 9.954 mW ______________ ______________ 10.046 mW
31.6228 mW 31.477 mW ______________ ______________ 31.769 mW
100 mW 99.54 mW ______________ ______________ 100.46 mW
Power Reference
P
meas
0.991 mW ______________ ______________ 1.009 mW
Interface Test Pass/Fail ______________ ______________ Pass/Fail
Functional Test
Low Range, 30 dBm pad Pass/Fail ______________ ______________ Pass/Fail
Upper Range, 30 dBm pad Pass/Fail ______________ ______________ Pass/Fail
