106 Chapter 5
Post-Repair Procedures
Post-Repair Procedures
A50 CPU
module
No adjustment needed Inspect the Booting Process
DSP Card Perform the following required
adjustments using “A51 DSP board” in
Spot Adjustment of the program.
Writing ID
Inspect the Booting Process
Executed all of the performance test.
“To Check the Front Panel” on page 38
“To Check the External Trigger Input” on
page 41
Front Panel Board
No adjustment needed “To Check the Front Panel” on page 38
Handler I/O
Board
No adjustment needed “To Execute the Diagnostic Test” on page 31
HDD
Perform “HDD” (Hard Disk Drive) in Spot
Adjustment of the program.
Calibration of the Touch Screen (for opt.
016)
Inspect the Booting Process
Power Supply
Assembly
No adjustment needed Inspect the Booting Process
LCD
Not adjustment needed Inspect the Booting Process
“To Check the LCD” on page 40
Touch panel (for
Opt. 016)
Calibration of the Touch Screen Inspect the Booting Process
“To Check the Touch Panel” on page 39
Inverter Board
No adjustment needed Inspect the Booting Process
Table 5-1 Post-Repair Procedures (Option 3L5)
Replaced
Assembly or
Part
Required Adjustments
Correction Constants (CC)
Verification
To Next Page
