Chapter 2 19
Troubleshooting
How to exit from the E5061B Measurement View
2. Troubleshooting
How to exit from the E5061B Measurement View
You need to exit from the E5061B Measurement View to perform some troubleshooting.
The following is the procedure to exit from the E5061B Measurement View.
Step 1. Connect the mouse and external keyboard to the connectors on the E5061B rear panel.
Step 2. Turn the instrument on.
Step 3. Press key.
Step 4. Click Service Menu - Exit. Exit dialog box is as shown in Figure 2-1.
Figure 2-1 Exit dialog box
Step 5. Click OK in Exit Menu. Then the E5061B exit the Measurement View, then.windows
desktop screen appears.
NOTE If you wish to return to the Measurement View, double-click "Network Analyzer" icon.
NOTE If you need to shut down the E5061B and again turn on, perform in accordance with the
following procedure.
a. To get "Start" menu bar displayed, move the pointer to the bottom of the screen with
mouse.
b. Click "Start" and "Shut Down..." in the pull down menu. "Shut Down Windows" dialog
box opens.
c. Select "Shut down" button in the pull down menu.
d. Click "OK" button in the dialog box.
