Chapter 2 37
Troubleshooting
Function Specific Troubleshooting
2. Troubleshooting
To Check the Device Driver
Make sure first whether the E5061B device drivers are installed properly or not by the
following procedure, if a function of specific device in the E5061B doesn't work.
Step 1. Exit from the E5061B measurement view in accordance with the procedure described in
“How to exit from the E5061B Measurement View” on page 19. Then, Windows desktop
screen is displayed.
Step 2. Click "My Computer" with the right button and select "Properties" as shown in Figure
2-17. Then, the System Properties(Figure 2-18) will appear.
Figure 2-17 Opening System Property Window
Figure 2-18 System Properties Window (General)
Step 3. Click Hardware tab and Device Manager button. The operating system detects all the
necessary device drivers and displays the device names as shown in
Figure 2-19.
To Next Page
