70 Chapter 4
Replacement Procedure
DSP Assembly Replacement
DSP Assembly Replacement
Tools Required
• torque screwdriver, T15, and T20
• torque screwdriver, T10 (set to 9 in-lb)
• box torque wrench, 5/8 inch (set to 30.4 in-lb)
• flat edge screwdriver
Removal Procedure
Refer to Figure 4-9 for this procedure.
Step 1. Remove the Outer Cover as described in “Outer Cover Replacement” on page 54.
Step 2. Remove the Front Panel as described in “Front Panel Replacement” on page 56.
Step 3. Disconnect the flat cable (item 1) from the DSP Assembly.
Step 4. Disconnect the two S-ATA cable (item 2) from the DSP Assembly.
Step 5. Remove the two 5/8 inch nuts and the two washers (item 3) from the BNC connectors.
Step 6. Remove the two TORX T10 screws (item 4) fastening the DSP Assembly.
Step 7. Slide forward the DSP Assembly.
Replacement Procedure
Step 1. Reverse the order of the removal procedure.
NOTE Set a torque 30.4 in-lb for box torque wrench when fasten the 5/8 inch nuts and the washers
(item 3).
Set a torque to 9 in-lb for torque driver when fasten the TORX T10 screws (item 4).
