6-10 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Front Panel Assembly, All Options
Ref. Desig. Model Part Number Qty Description
A1 All E8356-60001 1 Keypad assembly
A2
a
a. When ordering a replacement A2 display assembly, you must also order item
➃
.
All E8356-60002 1 Display assembly
0950-3379 1
Inverter board (included in A2
b
)
b. Although included in the A2 display assembly, each of these parts is also available separately. If one of these parts should
have to be replaced, it is not necessary to replace the entire A2 display assembly. For any other parts failures within the
display, replace the entire A2 display assembly.
2090-0386 1
Display lamp for LCD (included in A2
b
)
1000-1161 1
Display glass (included in A2
b
)
A3 All E8361-60061 1 Front panel interface board
RPG All E8356-40006 1 Front knob
➀
All 5041-9183 2 With handles—front handle side trim
All 5041-9174 2 Without handles—trim strip, filler
➁
c
c. For part numbers of complete rack mount kits and handle kits, refer to “Rack Mount Kits and Handle Kits” on page 6-82.
All 5063-9205 2 Front handle
➂
All
E8364-80002
1
Front panel overlay, no options
Front panel overlay, option UNL or UNL/016
E8364-80003 Front panel overlay, option 014 or 014/080 or 014/080/081
E8364-80011
Front panel overlay, option UNL/014, UNL/014/080/081, or
UNL/014/080/081/H11
E8364-80024
Front panel overlay, option UNL/014/016, UNL/014/016/080,
UNL/014/016/080/081, UNL/014/016/080/081, H11
➃
E8362B E8362-80003
1 NameplateE8363B E8363-80002
E8364B E8364-80023
➄
d
d. When ordering a replacement front frame assembly, you must also order item
➂
.
All E8364-60015 1 Front frame assembly
➅
All 0515-0375 4 Machine screw, M3.0 x 14 pan head
➆
All 0515-0372 10 Machine screw, M3.0 x 8 pan head
➇
All
E8364-00020 1 Display cable retaining bracket
