3-40 Service Guide E8364-90026
Tests and Adjustments PNA Series Microwave Network Analyzers
Adjustments E8362B, E8363B, E8364B
Adjustments
These adjustments are firmware-driven tests that are used to fine-tune your analyzer for
optimum response.
If multiple adjustments are to be performed, perform them in the order listed.
• “10 MHz Frequency Reference Adjustment” on page 3-41
• “3.8 GHz PMYO Frequency Adjustment” on page 3-42
• “LO Power Adjustment” on page 3-43
• “LO Offset Adjustment” on page 3-45
• “Source Calibration Adjustment” on page 3-47
• “Phase Lock IF Gain Adjustment” on page 3-48
• “Receiver Calibration Adjustment” on page 3-49
