Agilent Technologies E8364B User Manual

6-44 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Bottom Assemblies, Options 014/080/081
Ref. Desig. Models Part Number
a
a. Part numbers in italic typeface are for rebuilt exchange assemblies. Refer to “Rebuilt-Exchange Assemblies” on page 6-5.
Qty Description
A16 All E8364-60138 1 Test set motherboard
A17 All
5087-7127
5087-6127
1 LOMA 10
A18 All
5087-7128
5087-6128
1MA 20
A19 All 5087-7139 1 Splitter
A20 All
5087-7129
5087-6129
1LODA
A21 E8363B, E8364B
5087-7130
5087-6130
1 SOMA 50
A22 All
5087-7132
5087-6132
1 Switch splitter
A23 E8363B, E8364B 5087-7242 1 Channel R1 detector
A24 E8363B, E8364B 5087-7133 2 Channel R2 detector
A25
A26
E8362B 5086-7968 2
Test port 1 coupler
Test port 2 coupler
E8363B, E8364B 5086-7518 2
Test port 1 coupler
Test port 2 coupler
A27
A30
All
5087-7122
5087-6122
2
Channel A first converter (mixer)
Channel B first converter (mixer)
A28
A29
5087-7145
5087-6145
2
Channel R1 first converter (mixer)
Channel R2 first converter (mixer)
A31
A32
A33
A34
All
E8364-60134
E8364-69134
4
Channel A receiver module
Channel R1 receiver module
Channel R2 receiver module
Channel B receiver module
A35 All E8364-60135 1 Receiver motherboard
A41 All Hard disk drive assembly. Refer to “Hard Disk Drive Assembly” on page 6-78.
A45
A46
All 5087-7238 2 50 GHz reference transfer switch
A49 All E8361-60043 1 IF multiplexer board
➀
E8362B 08493-60017 2 30-dB fixed attenuator (pad)
