6-74 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
External Hardware and Parts, All Options
Ref. Desig. Part Number Qty Description
A1 Keypad assembly
Refer to “Front Panel Assembly, All Options” on page 6-10.A2 Display assembly
RPG Front knob
➀
E8356-00011 1 Inner cover
➁
N5230-00011 1 Outer cover
➂
5041-9611 4 Rear feet
➃
0515-1619 4 Machine screw, M4.0 x 25, pan head
➄
E4400-60026 2
Strap handle assembly (includes item
➅
)
➅
0515-0710 4 Machine screw, M5.0 x 18, flathead
➆
5041-9167 4 Bottom feet
➇
5041-9183 2 With handles—front handle side trim
5041-9174 2 Without handles—trim strip, filler
➈
5063-9205 2 Front handle
➉
Front panel overlay
Refer to “Front Panel Assembly, All Options” on page 6-10.
Nameplate
E8364-60015 1 Front frame assembly
11
12
To Next Page
