6-76 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Rear Panel Assembly, All Options
Item Number Part Number Qty Description
➀
E8364-60023 1
Rear frame assembly (includes items
➁
–
➆
)
➁
E8356-00023 1 Cover plate, large
➂
6960-0149 10 Hole plug (only 2 installed if Option H11 is installed)
➃
0515-0372 33 Machine screw, M3.0 x 8, pan head
➄
8120-5055 2 BNC cable assembly
➅
2950-0035 4
Hex nut (for BNC cable assemblies
➄
and
➇
)
➆
2190-0102 4
Lock washer (for BNC cable assemblies
➄
and
➇
)
➇
8120-5027 2 BNC cable assembly
➈
E8356-00037 1
Cover plate, USB hub. Refer to
“Top Hardware, All Options”
on page 6-68
for the part number of the USB hub board.
➉
0515-0374 9 Machine screw, M3.0 x 10, pan head
E8361-00006 1 Test set motherboard rear panel (P/O A16)
85047-60005 2
Fuse holder (includes wire harness, nut, and washer)
a
a. See page 6-82 for the part number of the fuses.
1400-0112 2 Fuse holder cap
E8364-00018 1
Cover (not shown), for bias connectors and fuse holders
(Installed only on analyzers without Option UNL.)
These connectors are part of their respective cables. Refer to “Bottom Flexible Cables, All Options”
on page 6-64. Hole plugs (item
➂
) are installed here if Option H11 is not installed.
6960-0076 2 Hole plug (if Option H11 is not installed)
1250-1251 2 SMA connector, f-f
1810-0118 2 SMA coaxial termination, 50 ohm
E8364-60095 1 Hard disk drive stationary board with mating connector
0515-1410 2
Machine screw, M3.0 x 20, pan head (to secure item )
11
12
13
14
15
16
17
18
19
20
19
