Agilent Technologies E8364B User Manual

6-38 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Bottom Semi-Rigid Cables, Options UNL/016
Ref. Desig. Models Part Number Qty Description
W1
E8362B E8362-20002
1
A12 source 20 to A22 switch splitter
E8363B, E8364B E8364-20036 A12 source 20 to A21 SOMA 50
W2 E8363B, E8364B E8364-20034 1 A21 SOMA 50 to A22 switch splitter
W3
E8362B E8362-20003
1
A22 switch splitter to channel R1 30-dB attenuator
E8363B, E8364B E8364-20144 A22 switch splitter to A23 detector
W4
E8362B E8362-20004
1
A22 switch splitter to channel R2 30-dB attenuator
E8363B, E8364B E8364-20024 A22 switch splitter to A24 detector
W7
E8362B E8362-20039
1
Channel R1 attenuator to A28 channel R1 mixer
E8363B, E8364B E8364-20149 A23 detector to A28 channel R1 mixer
W8
E8362B E8362-20040
1
Channel R2 attenuator to A29 channel R2 mixer
E8363B, E8364B E8364-20150 A24 detector to A29 channel R2 mixer
W9 All E8364-20019 1 A25 test port 1 coupler to A27 channel A mixer
W10 All E8364-20020 1 A26 test port 2 coupler to A30 channel B mixer
W11 All E8364-20171 1 A20 LODA to A27 channel A mixer
W12 All E8364-20172 1 A20 LODA to A28 channel R1 mixer
W13 All E8364-20173 1 A20 LODA to A29 channel R2 mixer
W14 All E8364-20146 1 A20 LODA to W40 (to A30 channel B mixer)
W15 All E8364-20041 1 A19 splitter to A20 LODA
W16 All E8364-20042 1 A19 splitter to A20 LODA
W17 All E8364-20029 1 A18 MA 20 to A19 splitter
W18 All E8364-20145 1 A17 LOMA 10 to A18 MA 20
W19-W20 All
Refer to “Top Cables–All, All Options Except 080” on page 6-14
.
W40 All E8364-20032 1 W14 (from A20 LODA) to A30 channel B mixer
W45 All E8364-20147 1 A25 test port 1 coupler to A43 channel A step attenuator
W46 All E8364-20148 1 A26 test port 2 coupler to A44 channel B step attenuator
W47 All E8364-20131 1 A43 channel A step attenuator to A27 channel A mixer
W48 All E8364-20132 1 A44 channel B step attenuator to A30 channel B mixer
W51 All E8364-20055 1 A22 switch splitter to A36 step attenuator
W52 All E8364-20056 1 A22 switch splitter to A37 step attenuator
W53
All E8364-20077 2
A36 step attenuator to A38 bias tee
W54 A37 step attenuator to A39 bias tee
W55 All E8364-20167 1 A38 bias tee to A25 test port 1 coupler
W56 All E8364-20168 1 RF cable: A39 bias tee to A26 test port 2 coupler
