6-64 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Bottom Flexible Cables, All Options
Ref. Desig. Models Part Number Qty Description
W21 All E8364-60019 1
A27 channel A mixer
to A49 IF multiplexer board
W22 All E8364-60020 1
A28 channel R1 mixer
to A49 IF multiplexer board
W23 All E8364-60021 1
A29 channel R2 mixer
to A49 IF multiplexer board
W24 All E8364-60022 1
A30 channel B mixer
to A49 IF multiplexer board
W25 All E8364-60126 1
A31 receiver A J400
to A6 SPAM board J3
W26 All E8364-60127 1
A32 receiver R1 J400
to A6 SPAM board J4
W27 All E8364-60128 1
A33 receiver R2 J400
to A6 SPAM board J5
W28 All E8364-60129 1
A34 receiver B J400
to A6 SPAM board J6
W29 All E8364-60124 1
A10 frequency reference board J4
to A35 receiver motherboard J2
W30 All E8364-60125 1
A35 receiver motherboard J50
to A11 phase lock board J6
W36 All E8364-60161 1
A16 test set motherboard J15
to A49 IF multiplexer board J1
W37 E8363B, E8364B E8364-60121 1
A16 test set motherboard
to A23 detector
W38 E8363B, E8364B E8364-60122 1
A16 test set motherboard
to A24 detector
W39 E8363B, E8364B E8364-60123 1
A16 test set motherboard
to A21 SOMA 50
W41
All 8120-5014 1
A49 IF multiplexer board
to A31 receiver A
W42
A49 IF multiplexer board
to A32 receiver R1
W43
A49 IF multiplexer board
to A33 receiver R2
W44
A49 IF multiplexer board
to A34 receiver B
W101-
W104
All with Option H11 8120-5401 8
Rear panel 8.33 MHz IF IN connectors
to A49 IF multiplexer board
W105-
W108
Rear panel PULSE IN connectors
to A49 IF multiplexer board
W116 All with Option 080
Refer to “Top Cables–All, All Options Including 080” on page 6-18
.
