Agilent Technologies E8364B User Manual

6-66 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Bottom Ribbon Cables and Wrapped-Wire, All Options
Ref. Desig. Type
a
a. nW = n wires in a wrapped cable; nR = n wires in a ribbon (flat) cable
Part Number Description
➀
50R 8121-0817
A41 hard disk drive assembly
to A15 CPU board
➁
40R 8121-0834
A16 test set motherboard P701 (MAT HDLR)
to rear-panel connector, Handler I/O
➂
26R 8121-0818
A21 SOMA 50 (E8363B/E8364B only)
to A16 test set motherboard J4 (SOMA50)
➃
60R 8121-0965
A16 test set motherboard J2 (RCVR)
to A35 receiver motherboard and A49 IF multiplexer board
➄
16R 8121-0816
A20 LODA
to A16 test set motherboard J11 (LODA)
➅
24R 8121-0815
A18 MA 24
to A16 test set motherboard J7 (MA20)
➆
20R 8121-0846
A17 LOMA 12
to A16 test set motherboard J10 (LOMA10)
➇
2W 8121-0966
A45 reference transfer switch
to A16 test set motherboard J31 (-SW1)
A46 reference transfer switch
to A16 test set motherboard J30 (+SW1)
➈
2W 8121-0803
A22 switch splitter
to A16 test set motherboard J500
➉
20R E7340-60075
A23 detector (E8363B/E8364B only)
to A16 test set motherboard J5 (R1 DET)
A24 detector (E8363B/E8364B only)
to A16 test set motherboard J6 (R2 DET)
10R 8121-0819
A43 receiver step attenuator
to A16 test set motherboard P500 (P1 RCVR ATT)
A44 receiver step attenuator
to A16 test set motherboard P501 (P2 RCVR ATT)
10R 8121-0819
A36 source step attenuator
to A16 test set motherboard P510 (P1 SRC ATT)
10R 8121-0119
A37 source step attenuator
to A16 test set motherboard P512 (P2 SRC ATT)
14R 8121-0814
Mixer bias board
to A16 test set motherboard J3 (MIXERS)
4W 8121-0802
Front-panel LED board
to A16 test set motherboard J502
100R 8121-0118
A16 test set motherboard J1
to A14 system motherboard J8
11
12
13
14
15
16
