2-10 Service Guide E8364-90026
General Product Information PNA Series Microwave Network Analyzers
Required Service Test Equipment E8362B, E8363B, E8364B
Equipment
a
Critical Specifications
Recommended
Model or Part
Number
Alternate
Model or Part
Number
Use
b
Calibration and Verification Kits
Type-N calibration kit
(E8362B)
Freq: 10 MHz to 20 GHz 85054B 85054D P,T
Type-N verification kit
(E8362B)
Freq: 10 MHz to 20 GHz 85055A None V
3.5 mm calibration kit
(E8362B, E8363B, E8364B)
Freq: 10 MHz to 20, 40, or
50 GHz
85052B 85052D P,T
3.5 mm verification kit
(E8362B, E8363B, E8364B)
Freq: 10 MHz to 20, 40, or
50 GHz
85053B None V
2.4 mm calibration kit
(E8363B, E8364B)
Freq: 10 MHz to 40 or
50 GHz
85056A 85056D P,T
2.4 mm verification kit
(E8363B, E8364B)
Freq: 10 MHz to 40 or
50 GHz
85057B None V
Cables
BNC cable (2 required) 50Ω, length ≥ 60 cm 8120-1839 None A
3.5 mm RF cable (Qty 2)
(E8362B)
50Ω, length ≥ 60 cm 85131C 85131E P,A,V
2.4 mm RF cable (Qty 2)
(E8363B, E8364B)
50Ω, length ≥ 60 cm 85133C 85133E P,A,V
GPIB cable N/A 10833A/B/C/D None P,A
Adapters
3.5 mm (f) to 3.5 mm (f)
(E8362B)
Return Loss: ≥ 32 dΒ 83059B
85052-60012
c
P, A ,T
3.5 mm (f) to type-N (m)
(E8362B)
Return Loss: ≥ 28 dΒ 1250-1743 None P,A,T
2.4 mm (f) to 2.4 mm (f)
(E8363B, E8364B)
Return Loss: ≥ 26 dΒ 11900B
85056-60007
d
P, A ,T
2.4 mm (f) to type-N (m)
(E8363B, E8364B)
Return Loss: ≥ 28 dΒ 11903D None P,A,T
Attenuators
3.5 mm (m,f), 10-dB fixed
attenuator
(E8362B)
Accuracy: ± 0.5 dB
Freq: 10 MHz to 20 GHz
8493C
Option 010
None P
3.5 mm (m,f), 20-dB fixed
attenuator
(E8362B)
Accuracy: ± 0.5 dB
Freq: 10 MHz to 20 GHz
8493C
Option 020
None P
2.4 mm (m,f), 10-dB fixed
attenuator
(E8363B, E8364B)
Accuracy: ± 0.5 dB
Freq: 10 MHz to 40 or
50 GHz
8490D
Option 010
None P
2.4 mm (m,f), 20-dB fixed
attenuator
(E8363B, E8364B)
Accuracy: ± 0.5 dB
Freq: 10 MHz to 40 or
50 GHz
8490D
Option 020
None P
a. Unless specified otherwise, equipment listed is required for all analyzer models.
b. P = Performance tests, A = Adjustments, T = Troubleshooting, R = Repair, V = System verification
c. Included in the 85052B/D calibration kits.
d. Included in the 85056A/D calibration kits.
