Service Guide E8364-90026 3-3
PNA Series Microwave Network Analyzers Tests and Adjustments
E8362B, E8363B, E8364B Information in This Chapter
Preliminary Checks
Performing the operator’s check.
Checking your test cables.
Perform these checks before performing system
verification.
Page 3-11
System Verification
What the system verification does.
How to perform the verification test.
How to interpret the results.
Page 3-20
Option H11, IF Access,
Operation Verification
How to verify the operation of Option H11, IF access. Page 3-30
Performance Tests
(Agilent N7840A
Software Package)
a
A brief summary of each performance test in the
Agilent N7840A software package:
• Source Power Accuracy Test
• Source Power Linearity Test
• Frequency Accuracy Test
• Trace Noise Test
• Receiver Compression Test
• Noise Floor Test
• Calibration Coefficient Test
• System Crosstalk Test
• Dynamic Accuracy Test
Page 3-31
Adjustments
Setups and procedures for adjusting your analyzer:
• Source Calibration Adjustment
• Receiver Calibration Adjustment
• LO Power Adjustment
• 10 MHz Frequency Reference Adjustment
• 3.8 GHz PMYO Frequency Adjustment
Page 3-40
a. The Agilent N7840A software package must be purchased separately.
Section Title Summary of Content Start Page
To Next Page
