20 Chapter 2
Installation
Environmental Requirements
Protection Against Electrostatic Discharge (ESD)
Set up a static-safe work-station to protect the electronic components from the damage by
the electrostatic discharge (ESD) as shown in Figure 2-3. Table 2-2 shows the accessories
available that provide ESD protection.
Figure 2-3 Example of the static-safe work-station
Ensuring Adequate Free Space around Analyzer for Immediate
Disconnection of Power Cable in Case of Emergency
As described in “Disconnection from Supply Source” on page 32, the power supply is
disconnected by removing the power cable’s connector plug from either the AC outlet or
the E5061A/E5062A unit. When installing the E5061A/E5062A, ensure that there is
sufficient free space around the unit to permit quick disconnection of the plug (from AC
outlet or E5061A/E5062A unit) in case of emergency.
Table 2-2 The accessories available that provide ESD protection
Name Agilent Part Number
Static-control table mat and earth ground wire 9300-0797
Wrist-strap cord 9300-0980
Wrist-strap 9300-1383
Heel-straps 9300-1169
