Chapter 3 51
Quick Start Guide
Basic Measurement Procedures
3. Quick Start Guide
Basic Measurement Procedures
To better understanding how to use the E5061A/E5062A, this section describes the basic
measurement procedure using the E5061A/E5062A and presents an example of the
transmission measurement of a bandpass filter.
Basic Measurement Flow
STEP 1. Determining measurement conditions
R Presetting the E5061A/E5062A
R Selecting the S-parameter
R Selecting the data format
R Specifying the frequency range
R Specifying the number of measurement points
R Specifying the power level
R Specifying the IF bandwidth
STEP 2. Calibration
R Specifying the calibration kit
R Selecting the calibration type
R Measuring the calibration data
R Making the error correction ON
R Saving the calibration data
STEP 3. Connecting the device under test (DUT)
R Connecting the device under test (DUT)
R Adjusting the scale
STEP 4. Analyzing measurement results
R Analysis using the markers
STEP 5. Outputting measurement results
R Storing the measurement file to a disk
