28 Chapter 2
Installation
Power Supply and Blown Fuses
Power Supply and Blown Fuses
Before turning on the E5061A/E5062A power, check the following.
Verification of the Power Supply
Confirm that the power supplied to the E5061A/E5062A meets the following
requirements:
Verification and Connection of Power Cable
The three-wire power cable attached to the E5061A/E5062A has one wire serving as a
ground. Using this power cable allows the E5061A/E5062A to be grounded, thereby
protecting you against electrical shock from the power outlet.
Step 1. Confirm that the power cable is not damaged.
WARNING NEVER use a power cable showing any sign of damage. Faulty cables can cause
electrical shock.
Step 2. Use the supplied cable to connect between the power cable receptacle (Figure 2-10 on
page 32) on the rear panel of the E5061A/E5062A and a three-wire power outlet with the
grounding prong firmly connected in the ground slot.
WARNING Use the supplied power cable with grounding wire to securely ground the
E5061A/E5062A.
Figure 2-9 shows the power cable options.
Requirements
Vo l t a g e
90 to 132 VAC or 198 to 264 VAC
*1
*1. Switched automatically by the E5061A/E5062A in conformity to the voltage used.
Frequency 47 to 63 Hz
Maximum power consumption 350 VA
