1290 Infinity Quaternary Pump User Manual 249
Hardware Information
12
Interfaces
• CAN connectors as interface to other modules
• LAN connector as interface to the control software
• RS- 232C as interface to a computer
• REMOTE connector as interface to other Agilent products
• Analog output connector(s) for signal output
G4227A Flex Cube 2 No No No No No CAN-DC- OUT for CAN
slaves
2
G4240A CHIP CUBE 2 Yes No Yes No Yes CAN-DC- OUT for CAN
slaves
THERMOSTAT for
G1330A/B (NOT
USED), K1330B
1
Requires a HOST module with on-board LAN (e.g. G4212A or G4220A with minimum firmware B.06.40 or C.06.40) or with ad-
ditional G1369C LAN Card
Tabl e 7 Agilent 1200 Infinity Series Interfaces
Module CAN LAN/BCD
(optional)
LAN
(on-board)
RS-232 Analog APG
Remote
Special
The detector (DAD/MWD/FLD/VWD/RID) is the preferred access point for control via
LAN. The inter-module communication is done via CAN.
