1260 Infinity II Flexible Pump User Manual 151
8Maintenance
Introduction to Maintenance
Introduction to Maintenance
Figure 19 on page 151 shows the main user-accessible assemblies of the Agilent
1260 Infinity II Flexible Pump. These parts can be accessed from the front
(simple repairs) and don’t require to remove the pump from the system stack.
Figure 19 Overview of maintenance parts for the Flexible Pump
Seal Wash Sensor
Seal Wash Pump
Jet Weaver (optional)
Multi-Channel
Gradient Valve (MCGV)
Inlet Weaver
Pump Head Assembly
Multipurpose Valve
Pressure Sensor
Filter Housing
High Pressure
Degasser
