1260 Infinity II Flexible Pump User Manual 243
9 Parts and Materials for Maintenance
Pump Heads (G7104C)
Secondary Pump Head Parts
Secondary Pump Head Assembly Pendulum (G4220-60660)
Item p/n Description
1 5067-5975 Plunger Assy ZrO
2
LL
2 5810-0009 Screw M5x40 A4-80 Lubric Silver
3 G4220-60046 Preload-Support Assembly LL
4 0905-1175 Wash seal (PTFE)
5 G4220-60616 Seal Holder Integrated Assembly EM/LL
6 0905-1719 PE Seal
7 G4220-25513 Body Head Secondary EM/LL
8 G4220-20001 Spacer Fitting
9 5023-3119 Screw M5x10 Planar Front
10 G4220-20000 LID
11 G4220-20003 Pump Head Screw
