12 LAN Configuration
Configuration Switch
1260 Infinity II Flexible Pump User Manual 284
Configuration Switch
The configuration switch can be accessed at the rear of the module.
Figure 30 Location of Configuration Switch
The module is shipped with all switches set to OFF, as shown above.
Configuration switch
NOTE
To perform any LAN configuration, SW1 and SW2 must be set to OFF.
Table 23 Factory Default Settings
Link Configuration speed and duplex mode determined by auto-negotiation, for
details see “Link Configuration Selection” on page 290
