1260 Infinity II Flexible Pump User Manual 225
8Maintenance
Replace Parts of the Inline Filter
3 Use two 5/16 wrenches for opening the inline filter. 4 Replace the filter frit and reassemble the inline filter.
5 Put the inline filter to the clamp and install its capillaries.
The integrated capillary is connected to port 5 of the
Multi Purpose Valve. The removable capillary is
connected to port 8.
Filter frit
Port 5
Port 8
capillary
Integrated
capillary
Removable
