1260 Infinity II Flexible Pump User Manual 89
4 Preparing the Pump
Installing Capillaries
Table 14 Capillary connections for 1290 Infinity II systems
p/n From To
Bottle Head Assembly (G7120-60007) Solvent Bottle Infinity II Pump
Capillary ST 0.17 mm x 400 mm SI/SI (5500-1245) Pump Sampler
Capillary, ST, 0.17 mm x 900 mm SI/SX (5500-1217) Pump Vialsampler with ICC
Capillary ST 0.12 mm x 500 mm SL/S (5500-1157) Multisampler MCT Valve/Heat Exchanger
Capillary ST 0.12 mmX 400 mm SL/SL (5500-1251) Vialsampler MCT Valve/Heat Exchanger
Capillary ST 0.12 mm x 105 mm SL/SL (5500-1238) Vialsampler ICC Heat Exchanger
Capillary ST 0.12 mm x 120 mm SL/SL, long socket
(5500-1249)
ICC Heat Exchanger Column
Capillary ST 0.12 mm x 105 mm SL (5500-1201) MCT Heat Exchanger Column
InfinityLab Quick Turn Capillary ST 0.12 mm x 280 mm, long
socket (5500-1191)
Column/MCT Valve Detector
Waste accessory kit (5062-8535) VWD Waste
Tube PTFE 0.7 mm x 5 m, 1.6 mm od (5062-2462) DAD/FLD Waste
Analytical tubing kit 0.25 mm i.d. PTFE-ESD (G5664-68712) Detector Fraction Collector
Table 15 Capillary connections for 1260 Infinity II Bio-inert LC
p/n From To
Bottle Head Assembly (G7120-60007) Solvent Bottle Infinity II Pump
Capillary Ti 0.17 mm x 500 mm, SL/SLV (5500-1264) Pump Multisampler
Capillary PK/ST 0.17 mm x 500 mm, RLO/RLO (Bio-inert)
(G5667-81005)
Multisampler MCT
ZDV union (Bio-inert) (5067-4741) Capillary Bio-inert Heat Exchanger
Quick Connect Heat Exchanger Bio-inert (G7116-60041)
Capillary Kit Flow Cells BIO includes Capillary PK 0.18 mm x
1.5 m and PEEK Fittings 10/PK (p/n 5063-6591)
(G5615-68755)
Column/MCT Valve Detector
Waste accessory kit (5062-8535) VWD Waste
Tube PTFE 0.7 mm x 5 m, 1.6 mm od (5062-2462) DAD/FLD Waste
Analytical tubing kit 0.25 mm i.d. PTFE-ESD (G5664-68712) Detector Fraction Collector
