Agilent InfinityLab LC Series Diode Array Detectors User Manual 16
1 Introduction
Optical System
Figure 6 Max-Light Cartridge Flow Cell
Slit Assembly
Programmable Slit (G7117B)
The micro-slit system makes use of the mechanical properties of silicon
combined with the precise structuring capabilities of bulk micro-machining. It
combines the required optical functions — slit and shutter — in a simple and
compact component. The slit width is directly controlled by the micro-processor
of the instrument and can be set as method parameter.
Figure 7 Slit Assembly
The slit width influences the spectral resolution and noise.
NOTE
For additional information on the Max-Light Cartridge flow cell refer to “Choosing
a Flow Cell” on page 78 and “Inline Pressure Relief Valve Kit (G4212-68001)” on
page 81.
