Making Your First Measurements
Running the Graphical Measurement Application (GMA) N4017A.
Chapter 2 35
Step 3. Connecting the Test Set
Refer to “Connecting USB, GPIB or LAN” on page 18.
Step 4. Using the GMA
1. Check the EUT is powered and is discoverable (see manufacturer’s handbook
for information).
2. Connect the EUT directly or via an antenna as shown in Figure 2-16.
Figure 2-16 Test Set RFIO Connections
3. Minimize the Connection Expert program.
4. Run the GMA program from the windows task bar using, Start>All
Programs>Agilent N4017A Bluetooth GMA>N4017A Bluetooth GMA or
double click the desktop icon if created during the installation.
N4010-90086.book Page 35 Monday, November 18, 2013 9:20 AM
