Making Your First Measurements
Running the Graphical Measurement Application (GMA) N4017A.
Chapter 236
5. Use the Instrument Selector to locate your Test Set from the appropriate
connection you have made. If you do not see your Test Set then expand the
appropriate connection type by clicking on the + symbol.
Figure 2-17 Typical GMA Instrument Selector Screen
6. Double Click your Test Set listing or Click on Select Instrument.
7. The GMA finishes loading and your Test Set’s display turns yellow.
8. In the GMA program, click on the Test Mode Link tab.
9. Click on Connection Control.
