30 U1731B/U1732B User’s and Service Guide
4 Specifications
Capacitance (Parallel Mode), Test Frequency = 100 Hz/120 Hz
Capacitance (Parallel Mode), Test Frequency = 1 kHz
Range Maximum
Display
Accuracy Specified Note
Capacitance DF
10 mF 19.99 mF
*
3.0% + 5 (DF<0.1) 10.0% + 100/Cx + 5 (DF<0.1) After short cal.
1000 µF 1999.9 µF
†
1.0% + 5 (DF<0.1) 2.0% + 100/Cx + 5 (DF<0.1) After short cal.
200 µF 199.99 µF 0.7% + 3 (DF<0.5) 0.7% + 100/Cx + 5 (DF<0.5) -
20 µF 19.999 µF 0.7% + 3 (DF<0.5) 0.7% + 100/Cx + 5 (DF<0.5) -
2000 nF 1999.9 nF 0.7% + 3 (DF<0.5) 0.7% + 100/Cx + 5 (DF<0.5) -
200 nF 199.99 nF 0.7% + 5 (DF<0.5) 0.7% + 100/Cx + 5 (DF<0.5) After open cal.
20 nF 19.999 nF 1.0% + 5 (DF<0.1) 2.0% + 100/Cx + 5 (DF<0.1) After open cal.
* This reading can be extended up to 1999 MAX display with accuracy that is not specified.
† This reading can be extended up to 19999 MAX display with accuracy that is not specified.
Range Maximum
Display
Accuracy Specified Note
Capacitance DF
1 mF 1.999 mF
*
3.0% + 5 (DF<0.1) 10% + 100/Cx + 5 (DF<0.1) After short cal.
200 µF 199.99 µF 1.0% + 5 (DF<0.1) 2.0% + 100/Cx + 5 (DF<0.1) After short cal.
20 µF 19.999 µF 0.7% + 3 (DF<0.5) 0.7% + 100/Cx + 5 (DF<0.5) -
2000 nF 1999.9 nF 0.7% + 3 (DF<0.5) 0.7% + 100/Cx + 5 (DF<0.5) -
200 nF 199.99 nF 0.7% + 3 (DF<0.5) 0.7% + 100/Cx + 5 (DF<0.5) -
20 nF 19.999 nF 0.7% + 5 (DF<0.5) 0.7% + 100/Cx + 5 (DF<0.5) After open cal.
2000 pF 1999.9 pF 1.0% + 5 (DF<0.1) 2.0% + 100/Cx + 5 (DF<0.1) After open cal.
* This reading can be extended up to 1999 MAX display with accuracy that is not specified.
