agria Multi-Purpose Machine 400E/400K 27
3
3. Devices and Operating Elements
Engagements of Drive-Wheels
l Rigid drive: Push both drive-wheels
inwards to a stop, engage detent springs
into inner ring grooves (fig. K). If detent
springs do not engage, turn drive-
wheels slightly and push them axially
inwards until you feel toothed clutch
wheel engage.
l Neutral: Push both drive-wheels out-
wards and lock detent springs into outer
ring groove (fig. L).
l Drive with differential effect: En-
gage one drive-wheel into inner ring
groove (fig. K), engage the second drive-
wheel into outer ring groove (fig. L) –
neutral.
K
L
