28 agria Multi-Purpose Machine 400E/400K
3. Devices and Operating Elements
Anti-Wind-On Pipes
To the mowing attachment anti-wind-on
pipes are delivered. Mount them on both
sides of the wheel-shaft between trans-
mission housing and drive-wheel (fig.
M).
Generally, these pipes prevent grass
from winding onto shaft. Remove
wound-on grass by simply dismounting
drive-wheels and anti-wind-on pipes
without tools.
Twin-Wheels
l Dismount single drive-wheels.
l Mount twin-wheels onto wheel-shaft
(as described in “Mounting Drive-
Wheels”).
l Fit special anti-wind-on pipes onto
wheel-shaft of twin-wheels – ensure that
valves fit into recesses.
l Mount single drive-wheels onto full
dog points of twin drive-wheels.
Cage Drive-Wheels
l Dismount drive-wheels.
l Mount cage drive-wheels onto wheel-
shaft (as described in “Mounting Drive-
Wheels”).
I
Rigid drive, neutral, drive with
differential effect can also be
engaged with twin and cage drive-
wheels mounted.
M
3
