MIL-STD-1553 Reference Manual
66
Chapter 3 – System Functions
Note: When setting the parameter sc to 6,7,8,11,12 or 13 on an AMC1553-1/-
2/-4 board the test will not be run and the result „Selftest Passed“ will
be returned, because the hardware parts are not available on the
AMC1553-1/-2/-4.
Output
A
A
i
i
U
U
I
I
n
n
t
t
8
8
b
b
i
i
t
t
e
e
_
_
s
s
t
t
a
a
t
t
u
u
s
s
[
[
]
]
Selftest results
The two returning selftest status bytes are comprising the following information:
Description
[0]
[1]
Constant
Selftest Passed
0
0
API_BITE_PASSED
Board Enable Test error
1
API_BITE_ERR_BOARD_ENABLE
Internal Selftest error
Memory Tests
- Addressing Test
- Pattern Test 0x5555
- Pattern Test 0xAAAA
- Pattern Test 0xFFFF
- Pattern Test 0x0000
- Walking Zero Test
- Walking One Test
PBI Test
- Wrong PBI ID Code
MILBus Test
2
16
17
18
19
20
21
22
23
24
API_BITE_ERR_INTERN_SELFTEST
API_BITE_ERR_INT_ADDR
API_BITE_ERR_INT_PAT_55
API_BITE_ERR_INT_PAT_AA
API_BITE_ERR_INT_PAT_FF
API_BITE_ERR_INT_PAT_00
API_BITE_ERR_INT_WALK_0
API_BITE_ERR_INT_WALK_1
API_BITE_ERR_INT_WRONG_PBI
API_BITE_ERR_INT_MILBUS
Global RAM Test error
BIU Control Block area
- Data Pattern Test
- Walking Bit Test
- Addressing Test
- Bus Test
3
1
2
3
4
API_BITE_ERR_GLOBAL_RAM_BIU
API_BITE_ERR_DATA_PATTERN
API_BITE_ERR_WALKING_BIT
API_BITE_ERR_ADDRESSING
API_BITE_ERR_BUS
Global RAM Test error
BIU BC/RT Descriptor area
- Data Pattern Test
- Walking Bit Test
- Addressing Test
- Bus Test
4
1
2
3
4
API_BITE_ERR_GLOBAL_RAM_BCRT
API_BITE_ERR_DATA_PATTERN
API_BITE_ERR_WALKING_BIT
API_BITE_ERR_ADDRESSING
API_BITE_ERR_BUS
Global RAM Test error
BIU BM area
- Data Pattern Test
- Walking Bit Test
- Addressing Test
- Bus Test
5
1
2
3
4
API_BITE_ERR_GLOBAL_RAM_BM
API_BITE_ERR_DATA_PATTERN
API_BITE_ERR_WALKING_BIT
API_BITE_ERR_ADDRESSING
API_BITE_ERR_BUS
Shared RAM Test error
(at 0x100000 offset)
Paging Test
6
1
API_BITE_ERR_SHARED_RAM
API_BITE_ERR_PAGING
